Voice Annunciator BDV
Voice Annunciator BDV
The BDV is an MP3 voice annunciator which produces excellent sound quality from pre-recorded MP3 files. The panel mounting style results in a clean, integrated look for most any application and programming it is easily accomplished with Patlite's SD card (sold separate) and Patlite's free (downloadable) programming software.
Azure function description

Product Features

· Only embedded mounting style available.
· Able to produce a loud sound of up to 87 dB (at 1m) despite its compact size
· A volume control on the front panel provides an easy way to adjust the sound volume.
· The use of an SD card allows message changes without dis-mounting the device.
· Environmentally friendly since the unit complies with the EU RoHS Directives.
· Several playback modes are available for various applications.
· Includes binary input as a standard option for selecting up to 15 messages.
· Supports input selection using NPN open-collector transistor.
· The unit complies with EU Directives and includes the CE mark (BDV-15JF only)
· Two colors are available for selecting the best color match for the installation.
· Protection rating: IP54 (only the front when flush mounted)

Model Specifications

DIMENSIONS - 80mm x 80mm x 94.7mm
- AC100/220V (1)
BODY COLOR - Dark Gray
- Light Gray
VOLUME - Maximum 87dB at 1 meter
SOUND STORAGE - Approximate Recording Time: 63 seconds (Bit rate=64k/s)
CHANNEL SELECTION - Select 1 of 4 channels available by signal input to 1 or 4 terminals
- In Binary Mode, select 1 of 15 channels available by signal inputs among 4 terminals
- RoHS
- MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thompson Licensing
FUNCTIONS - Sound Reduction Mode reduces volume by 10dB
